Tubeworks t/a The Works Construction Supplies is a main distributor for CSR Hebel, CSR AFS, and NRG Greenboard. CSR Hebel is an innovative building solution available in panels and blocks that are strong, versatile, and resilient. Being quick and easy to build with, better to line, and a sustainable building material.
CSR Hebel
CSR Hebel has been operational for over 25 years, meaning you can be assured you are getting a high-quality product with technical experts here to back you up.
CSR Hebel offers a comprehensive range of Autoclaved Aerated Concrete (AAC) panels and blocks in various sizes to suit different construction needs.
Hebel PowerPanel XL
Designed for residential and low-rise multi-residential buildings, these panels are 75mm thick and come in standard lengths:CSR Hebel+4CSR Hebel+4CSR Hebel+4
- 2400mm, 2550mm, 2700mm, 2800mm, 2850mm, 3000mm, and 3300mmCSR Hebel+2CSR Hebel+2CSR Hebel+2
Each panel is 600mm wide and weighs between 804kg and 1106kg per pack, with 10 units per pack.
Hebel PowerPanel
These panels are also 75mm thick and are available in lengths up to 4200mm. Made-to-order panels can extend up to 4800mm. Widths are typically 600mm. They come in both single mesh and caged (reinforced) designs, with weights ranging from 905kg to 1407kg per pack, depending on the length and mesh type.
Hebel PowerPanel50
Ideal for rendered exterior cladding and intertenancy walls, these 50mm thick panels are available in standard lengths:CSR Hebel+4CSR Hebel+4CSR Hebel+4
- 2400mm, 2550mm, 2700mm, 2850mm, and 3000mm
Each panel is 600mm wide and features steel reinforcement with an anti-corrosion coating.
Hebel PowerPanel+
These extra-thick panels range from 100mm to 300mm in thickness and are used for commercial and industrial applications. Lengths are made-to-order, and widths are typically 600mm. They are reinforced with caged steel and have an anti-corrosion coating.
Hebel PowerBlock
These blocks are 600mm long and come in various widths and thicknesses:
- Widths: 200mm, 250mm, 300mm, and 400mm
- Thicknesses: 50mm to 300mm
They are suitable for load-bearing external walls up to three storeys and non-load-bearing interior walls. Some blocks are designed for specific applications like bathroom hobs and decorative features.
Hebel PowerPattern
These panels are 75mm thick and are designed for facades with routed patterns. They are available in lengths of 3000mm and widths of 600mm. The panels feature V-grooves at intervals of 100mm, 150mm, 200mm, 300mm, or 600mm, depending on the pattern.
CSR AFS Rediwall
CSR AFS Rediwall is a versatile permanent formwork system for below- and above-ground wall applications. Its innovative system is made of prefabricated, high-quality panels and interconnecting components that simply snap or slide into place.
CSR AFS Rediwall® offers a versatile range of permanent PVC formwork panels suitable for various construction applications. These panels are designed to interlock seamlessly, providing a fast and efficient solution for building structural walls.Big River Building Products+4AFS Walling Solutions NZ+4Smart Permanent Formwork+4📏 Available Panel Sizes
The Rediwall® system includes panels in the following thicknesses and widths:InfraBuild
- 110 mm thickness – 250 mm width
- 156 mm thickness – 250 mm width
- 200 mm thickness – 250 mm width
- 256 mm thickness – 150 mm width
- 275 mm thickness – 250 mm width
- 300 mm thickness – 250 mm width
Panel lengths are typically customized to project requirements, allowing flexibility in design.
Curved Wall Panels
For projects requiring curved walls, the Rediwall® 200 Curve Panel is available. These panels come in 15-degree segments and can form curves with a minimum radius of 0.5 meters. They are offered in two standard heights: 3.0 meters and 3.6 meters. The panels are finished in the standard Rediwall® color and integrate seamlessly into the RW200 interlocking panel system.
NRG Greenboard
Tubeworks t/a The Works Construction Supplies is also a stockist and distributor of NRG Greenboard to the Victorian market. The NRG Greenboard™ is an insulated wall panel that combines exterior cladding with EPS insulation so designers can achieve the 6-star energy ratings that have been introduced into the building code.
The NRG Greenboard™ insulated core of high-quality expanded polystyrene positions the NRG Greenboard™ EPS cladding insulation options from 1.92R to 3.96R. Creating an exterior dual cladding system as a thermal exterior building envelope. NRG Greenboard™ EPS insulated wall panels are a lightweight, energy-efficient product, and once coated, the system provides a weather-resistant, seamless rendered finish.
NRG Building Systems (Aust) Pty Ltd furthermore supplies NRG Greenboard™ as an entire system, which gives building professionals the peace of mind that they are getting an entire wall system from start to finish. These include screws & washers, adhesives & sealants, render trims, mesh, renders, and textures.
NRG Building Systems (Aust) Pty Ltd also has a diverse range of other EPS products, such as architectural awnings and mouldings, internal insulation for floors, walls, and ceilings, and custom shapes and sizes required for any needs.
